Microprocessor Controller
A Microcontroller is a controlling device wherein the memory and I/O output component are present internally.
There are two types of input signal i.e Digital signal (110VDC) and Analog signal (0-10 VDC or 4-20mA).
| Basic Parameters | |
|---|---|
| Dimension (LxWxH) | 260x326x66 mm |
| Number of Analog inputs | 13 |
| Number of inputs | 22 |
| Number of outputs | 20 |
| Kind of output | Digital (Relay) |
| The programming method | USB |
| IP rating | IP50 |
| Supply voltage | 110AC/DC ±30% |
| Power Consumption | 11 W |
| Housing Material | Aluminium with Powder Coating |
| Display/Indicators | Colour LCD display |
| Communication | RS 485 |
| Data Logging | Yes (Can download via USB) |
| Operating & Service condition | |
| Maximum Speed of Train | 200km/h |
| Ambient | -4 to +55°C |
| Relative Humidity | Maximum Up to 98% |
| Atmosphere | Extremely dusty & desert weather |
